Home / Commercial Use Renewable Energy 3kw Wind Turbine Generator Price

  • >=1 Pieces
    $100.00
Type:
Wind Power Generator
Rated Power:
3000W
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 25 Negotiable
Customization:
Customized logo (Min. Order: 5 Pieces)
Graphic customization (Min. Order: 5 Pieces)

More

Customized packaging (Min. Order: 5 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ESG
Model Number:
3kW, ES-3000L
product name:
3KW Wind Turbine Generator
body material:
aluminium alloy
Application:
wind hybrid system , wind solar street light , off / on grid system
Lifespan:
Over 20years
Warranty:
3years
Certificate:
CE,ETL,ROHS, ISO
Delivery Time:
Delivery Time
Rated wind speed m/s:
12
Blade Number:
3 or 5 Blades
Supply Ability
Supply Ability:
10 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
wind turbine 1. PACKING: 1 pc 2. 20'FCL: 80-100 pcs 3. Giftbox meas. 1160mm*460mm*235mm 4. G.W. / N.W. 23 kg / 20kg
Port
SZ
Picture Example:
package-img
package-img
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 25 To be negotiated
Video Description



Product Description

   Home / Commercial Use Renewable Energy 3kw Wind Turbine Generator Price




CE certified for "Small Wind Turbine with High Reliability".
ISO certified for "Design, Development and Manufacture of Small Wind Turbine".
Amazingly quiet operation with little or no vibration.
Reliable two-moving-part maintenance free design. No problematic furling..
Fully automatic with blade aerodynamic braking and controller electromagnetic braking
High efficiency is achieved by matching design of the generator and blades perfectly.
Patented Blades with twisted aerodynamic design made with high-strength Nylon-fiberglass material
Easy installation, no welding needed. , 400W ~ 3000W wind generator.

 Aerodynamic Blade Design

Patented aerofoil 5 blade design with true symmetrical and twisted
aerodynamic design which ensures rotor capture maximum power from wind
(Cp>0.35 in low wind) and operates in amazingly low noise and minimal vibration.


- True symmetrical and balanced aerofoil blade ensure rotor matching with
generator perfectly.
- Large ratio of tip section chord to root section chord and variable chord
airfoil blade ensures rotor start-up easily and running smoothly with high
torque & RPM at lower wind condition
- Aerodynamic blades designed with over-speed braking system to make sure
generator well protected in higher wind.
- Reinforced nylon glass-fiber using advanced thermoplastic engineering and
precision injection molding technology for higher strength, flexibility and
reliability.

Model

ESG-3000

Rated Output

3000W

Peak Output

3500W

Rated Voltage

DC48v

Start-up Wind Speed

2.5m/s or 5.6m ph

Cut-in Wind Speed

3m/s or 6.7mph

Rated Wind speed

12m/s or 26.8mph

Working Temp. range

from -40°C to 60°C

Survival Max. wind

50m/s or 110mph

Over speed control

Electromagnetic & blade aerodynamic braking

Number of Blades

5

Rotor Diameter

2.05m

Swept Area

1.89m2

Blade Material

Nylon fiberglass reinforced composite

Generator Type

Brushless 3-phase PMA with high performance Neodymium Magnets

Tower-top Weight

70kg

Tower Type

self-supporting, guyed, tilt-up tower or rooftop mounting etc.

Controller Type

PWM

Applications

solar & wind hybrid lighting, off-grid power system etc.

Product Life

15 years

Warranty

3 years (optional 5 years)

Years on Market

7 years

Certificate

CE, RoHS, ETL, ISO9001:2008, ISO14001

Measurement

120*50*44cm

Gross Weight

84kgs

Production Flow

wordwide.jpgwind generator process.jpg

Vertical Wind Turbine Generator  QC control

1. Auto protection system: APS System
Anhua auto protection system, is selfdeveloped system. When wind speed is over 30m/s or output votlage is over rated, protection system will stop wind turbine, when wind speed is suitable, it will release wind turbine again.

 2.  Blade technology:

Choose aerofoil through wind tunnel test, optimize design according to aerodynamics, self design and manufactured blade

3. Generator technology:

Direct drive, wind rotor matches PM generator in optimum TSR vHigh efficiency, low start-up torque.
Allow continuous running in over speed and over load condition 1.5 times of rated speed and power
Maintenance free
ESG generator has passed the strict test in Germany. Output power, current and voltage all meet design requirements

Install & Testing

.jpg

produce2amber333.jpgamber111.jpgWIND01.pngamber222.jpg Dump.pngControllers.png

Certifications

wind generator certificates.jpg

Buyer Feedback

certificate wind.jpg

About us

ESG New Energy Technology Co. Ltd Committed to engage in off-grid solar and wind system, We are producing batteries, pure sine wave inverter,solar controller , wind and solar power generation system production, We have a production line and scientific quality management system. Development and sales of high-tech enterprises.

 Our factory has 29years history, we have 3 brand in China. ESG was established in 2013, a newest brand are specialized in solve green energy project.
